Dio110
Technology
TFT Meter
Real time status of your vehicle from one dashboard.
Idling Stop System
Automatically turns off the engine at stops, saving fuel.
PGM-FI Technology
Intelligent PGM-FI system for optimum air-fuel ratio
PGM-FI Technology
Intelligent PGM-FI system for optimum air-fuel ratio that provides superior performance, fuel savings, and reliable starts in any weather and lowered emissions.
Silent Start with ACG
Smooth, silent start every time.
Style
Comfort
Safety
Passing Switch
Pass like a boss with an easy-to-use passing switch for high beam, low beam, and passing with a flick.
Side Stand Engine Cut Off
It automatically shuts off the engine for added safety when the side stand is engaged.
Split Grabrail
A bold, sleek grabrail that grabs attention from the first glance onwards.
SPECIFICATION
Length:
1808 mm
1808 mm
Width:677 mm
Height:1151 mm
Wheelbase:1260 mm
Ground Clearance:160 mm
Kerb Weight:106 kg
Seat Length:650 mm
Seat Height: 765 mm
Fuel Tank Capacity:5.3 L
Type:4 Stroke, SI Engine
Displacement: 109.51 cc
Max Engine Output:5.85 kW @ 8000 rpm
Max Net Torque:9.03 Nm @ 5500 rpm
Fuel System:PGM-FI
Bore x Stroke: 47.10 X 63.121 mm
Compression Ratio:10:1
Starting Method:Self/Kick Start
Air Filter Type:
Viscous Paper Filter
Viscous Paper Filter
Clutch Type:
Automatic Centrifugal Clutch Dry Type
Automatic Centrifugal Clutch Dry Type
Tyre Size & Type (Front):
90/90-12 54J (Tubeless)
90/90-12 54J (Tubeless)
Tyre Size & Type (Rear):
90/100-10 53J (Tubeless)
90/100-10 53J (Tubeless)
Brake Type & Size (Front):
Drum – 130 mm
Drum – 130 mm
Brake Type & Size (Rear):
Drum – 130 mm
Drum – 130 mm
Frame Type:Under Bone
Front Suspension: Telescopic
Rear Suspension: Unit Swing
Battery:
12 V, 5.0 Ah (MF)
12 V, 5.0 Ah (MF)
Headlamp:
Halogen
Halogen
COLORS
